Start with a stationary check
Connect the cable between the input and output jacks and press the function button. CONDUCT begins by checking the cable in its static state, giving you a first step before checking how it behaves when moved.
Accessories
CONDUCT
Check the cable before chasing the signal.
CONDUCT is a guitar cable detector with static and dynamic checking. Connect both ends of a cable, start the test and follow the display prompts to check its behaviour at rest and during movement. The result appears on the onboard OLED, making it useful for checking cables before setup or troubleshooting.
- Static and dynamic cable checks
- On-screen test prompts and results
- USB-powered with one-button operation
View current pricing and availability on eBay.
What makes CONDUCT different
Check for movement-related problems
When the display prompts the dynamic stage, follow the shaking/movement instruction. This stage is intended to examine cable quality under movement, which adds a useful second check when a problem is not apparent in a stationary setup.
Read the result on the unit
The 0.96-inch OLED presents the test process and result without needing a computer display. A Micro-USB connection supplies 5 V power, while a single function switch keeps the checking sequence straightforward.
Make it part of your setup
- Power CONDUCT through Micro-USB and connect both ends of the guitar cable to its test jacks.
- Press the function button to begin the static check.
- Follow the display prompt for the dynamic check, then read the result on the OLED.
Product details
- Product
- CONDUCT
- Function
- Static and dynamic guitar cable checking
- Control
- Function toggle switch
- Display
- 0.96-inch OLED
- Connections
- Input jack, output jack, Micro-USB
- Power
- USB 5 V
- Current draw
- 100 mA
- Dimensions
- 72 × 64 × 15 mm
